Mutoh XPJ-C641SR Pro Print and Cut
A revolutionary benchtop vinyl sticker printer/cutter, engineered in Japan for professional-grade vinyl printing and contour cutting.
Weighing just 34kg with a compact footprint of 1,190mm x 438mm, this eco-solvent printer fits seamlessly into any workspace, making it the ideal small format printer cutter for start-ups, sign shops, and graphic designers.
Perfect for a diverse range of applications like custom vinyl stickers, t-shirt heat transfers, vehicle graphics, decals, posters, and banners. Integrating MUTOH's award-winning VerteLith RIP software for streamlined workflows and powered by advanced automation features, the XpertJet C641SR Pro ensures high-resolution eco-solvent ink printing and print-and-cut capabilities, boosting efficiency without compromising quality.
Desktop Print and Cut Production
Elevate your vinyl cutting machine game with this versatile, user-friendly desktop printer cutter—a game-changer for sticker production and custom decal printing.
Mutoh XPJ-C641SR Pro Features
DropMaster2
Automatic alignment of ink drops in bi-directional print modes allowing for high-speed printing with high detail.
Feed Master
Automatic calibration of media feed to ensure not banding between media types.
Media Tracker
Print a barcode before removing the media. Scan the barcode in when loading the media again to recognise the remaining media.
Nozzle Area Select
In the event of block nozzles not restoring, printing can continue using only the available nozzles.
Variable Head Height
Reduce the risk of head strike and maintain the highest quality print with the 2 stage head height adjustment.
MS31 Ink
GREENGUARD Gold certified ink delivers outstanding colour while allowing you to install printed graphics in high-sensitive environment like hospitals, childcare facilities etc.
Get More Done in Less Time
Powered by the innovative "AccuFine" print head, this machine delivers high-speed vinyl printing with exceptional image clarity. The "AccuFine" ensures vibrant, solid colour output with minimal banding, setting a new standard for precision vinyl sticker production.
Mutoh XPJ-C641SR Pro Specifications
| Print method | On-demand piezo drive system |
|---|---|
| Head height | Two-level adjustment. Low: 1.5mm, High: 2.8mm |
| Number of heads | 1 |
| Max. roll width | 630mm |
| Max. media thickness | Low 0.3mm, High 0.8mm |
| Media diameter | Φ150 mm or less |
| Core diameter | 2 or 3 inches |
| Max. media weight | 9kg or less |
| Max. print & Cut width | 590mm |
| Cutting speed | 20-150mm/sec |
| Cutting force | 30-300gf |
| Cut quality | 3 levels (quality, production, high-speed) |
| Ink type | MS31 eco-solvent. 4 colour (CMYK) |
| Ink capacity | 220ml cartridge / 1,000ml ink bag |
| Interface | Ethernet (10BASE-T / 100BASE-TX) |
| Power supply | Voltage: AC 100V～120V ±10% / AC 200V～240V ±10% Frequency: 50/60Hz ±1Hz |
| Operational environment | Temperature: 20℃～32℃ Humidity: 40%～60% No condensing |
| Power consumption during operation | 215W (800W peak) |
| Power consumption sleep mode | 13W or less |
| External dimensions | Width 1,190 mm x Depth 438 mm x Height 366 mm |
| Weight | Printer body: 34kg. Stand (optional) 10.2kg |
| RIP software | VerteLith (MUTOH genuine RIP software) |
